Mine Sieving Woven Wire Screen Mesh Galvanized Sandstone Mine

Name: Mine Sieving Woven Wire Screen Mesh Galvanized Sandstone Mine
Brand: MamBa
Price: 7.3020 USD

Wholesale Mine Sieving Woven Wire Screen Mesh Galvanized Sandstone Mine from china suppliers

Brand Name : MamBa

Model Number : Mine Sieving Mesh

Certification : CE

Place of Origin : HeBei,China

MOQ : 1500 Square Meter/Square Meters per Week

Price : $7.30 20 - 199 square meters

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 5000 Square Meter/Square Meters per Month

Delivery Time : 8-14 days

Packaging Details : 1.compacted before packaging. 2. Plastic packaging outside and on the pallet. or according to the customers' requirment

Weave style : Dutch Weave

Application : filter or sieving

Material : Stainless Steel Wire, Galvanized Wire, Mn Steel Wire

Type : Weave Wire Mesh

Product name : Mine sieving woven wire vibrating screen mesh Galvanized Sandstone Mine Screen Mesh

Hole shape : square hole and rectangle

Color : Silver,Black,Customized

Feature : alkali resist,acis resist,Corrosion Resistance,heat resistant

Contact Now

Mine Sieving Woven Wire Screen Mesh Galvanized Sandstone Mine

Products Description

Crimped Wire Mesh is made by carbon iron wire, galvanized steel wire or stainless steel wire.

Weaving Patterns: Weaving after crimping.

This kind of wire mesh is identified from a wire crimped only in the points of intersection, before weaving. Crimped wire mesh is only made on request and the wire used may be round or square.

Product Features:

Crimped woven wire mesh offers great dimensional strength and stability, great resistance to abrasion, uniform openings and excellent anti-corrosion. It is usually used as quarry screen in mine, quarry and other industrial fields as sieving, grading and separating screening materials.

Basic parameters:

Aperture width: 10 - 120mm in the case of multi-notch meshes and 4 - 40mm in the case of single-notch meshes.

Wire diameter: 1.0 - 5.5mm.

Mesh width: up to 2000mm.

Crimped wire mesh is supplied in the form of sheets.

Specification List of Crimped Wire Mesh/Wire Mesh for Roast

Wire Gauge SWG	Wire Diameter (mm)	Mesh/Inch	Aperture (mm)	Weight (kg/m2)
14	2.0	21	1	4.2
8	4.05	18	1	15
25	0.50	20	0.61	2.6
23	0.61	18	0.8	3.4
24	0.55	16	0.1	2.5
24	0.55	14	0.12	4
22	0.71	12	0.14	2.94
19	1	2.3	0.18	1.45
6	4.8	1.2	2	20
6	4.8	1	2	20
6	4.8	0.7	3	14
14	2.0	5.08	0.3	12
14	2.0	2.1	1	2.5
14	2.0	3.6	1.5	1.9

Mine Sieving Woven Wire Screen Mesh Galvanized Sandstone Mine

Weaving Types

Double crimp wire mesh

Double crimp wire mesh is manufactured with pre-crimped wires to obtain precise screening apertures and achieve maximum rigidity.
 Generally, it works well in conditions where materials are not sticky or materials with a small tendency to peg or wedge.

Flat Top Wire Mesh

Flat top wire mesh is manufactured with wires crimped on one side only to create a flat surface, thus enhancing its durability and
 allowing bigger apertures with high precision. It is generally used for coarse mineral screening.

Lock Crimp Wire Mesh

Double crimp wire mesh is manufactured with pre-crimped wires to obtain precise screening apertures and achieve maximum rigidity.
 Generally, it works well in conditions where materials are not sticky or materials with a small tendency to peg or wedge.

Mine Sieving Woven Wire Screen Mesh Galvanized Sandstone Mine

Applications

Applies to vibrating screens or stone crusher for sieving of mine and aggregates, as well as asphalt mixer plant in road

building.It also can be used in filtering and protection of petroleum, chemical industry and ocean industries with acid and alkali environment, making glass reinforce, various baskets for life and industrial use, art crafts, baskets used in the kitchen and the refrigerator.
