Pass Iso 9001 Metal Fine Mesh Screen High Durable Mining Mineral Separeting

  • 1
  • 2

Brand Name : Mam Ba

Model Number : Mining Screen Mesh Cloths

Certification : ISO9001,SGS

Place of Origin : China

MOQ : 10 Square Meter

Price : 1800-2500$/Ton

Payment Terms : L/C, T/T, D/A, D/P, O/AWestern Union, MoneyGram

Supply Ability : 10000SM/Week

Delivery Time : Within7-15days

Packaging Details : On Wooden or Iron Pallet

Mainly Material : Middle and High Carbon Steel Wire,304 Stainless Steel Wire

Tensile Stregth : 1000-1700Mpa

Weave Type : Plain Weave,Lock Type

Aperture : 1mm-152.4mm

Wire Diameter : 0.5-19.04mm

Wire Dia Tolerance : <3%

Aperture Tolerance : <3%

Processed Wire : Annealing Process

Surface Treat : Spray Anti-Rust Oil

Feature : High Durable

Screen Mesh Width : 500mm-2500mm

Products Name : Steel Wire Cloth

Advantage : Lower Cost,Higher Screening Efficiency and Easy to install and replace

Aperture Sizes : Square, Rectangle

Prouducts Type : bending hook or Flat Plate

Operating Temperature : below - 30ºC to 500 ℃

Contact Now

Mamba Mining Screen Mesh

Mamba Screen Mesh MFG Company, which is founded in 1989, has been devoted into wire cloth and screen media production for 33 years. The company owns 18 patented products, all of them have been up to EU, GB and ASTM standards. The company has acquired certificates of ISO 14001 Environmental Management System, ISO 9001 Quality Management System and OHSAS 18001 Occupation Health Safety Management System.

Mamba Screen Mesh MFG Company has a set of strict procedures to control the quality from materials to final products shipping. Our woven wire cloth has been widely accepted by clients from North America, Australia, Europe and Middle East for its high durability, precision and impact resistance. 90% of our

products are used in international markets because they can be perfectly matched with various kinds of vibrating screens including international brands. For all of mining, aggregate, asphalt mixing and road construction industries, every cent saved from high quality production, fast parts changes and a longer part wear life will be eventually converted into hard profits and real cost reduction of companies. As the most important part of vibrating screens, a set of high-quality wire cloth with high accuracy, long wear life and high anti-impact is the foundation of production quality assurance in all industries above.

Mining Screen Mesh Material:


highly abrasion-resistant spring steel wire or stainless spring steel wire.

No Grade Chemical Composition
C Si Mn
1 45 0.42-0.50 0.17-0.37 0.50-0.80
2 50 0.47-0.55
3 55 0.52-0.60
4 60 0.57-0.65
5 65 0.62-0.70
6 70 0.67-0.75
7 65Mn 0.62-0.70 0.90-1.20
8 72A 0.70-0.75 0.15-0.35 0.30-0.60

No Grade Chemical Composition
C Ni Mn Cr
1 304 ≤0.08 8.0-11.0 ≤2 18.0-20.0
2 321 ≤0.08 9.0-12.0 ≤2 17.0-19.0
3 316 ≤0.08 10.0-14.0 ≤2 16.0-18.5
4 2205 ≤0.03 4.5-6.5 2.5-3.5 21.0-24.0
5 2507 ≤0.03 6-8 ≤1.2 24-26

Pass Iso 9001 Metal Fine Mesh Screen High Durable Mining Mineral Separeting

Mining Screen Mesh Parameters:

Steel Wire Cloth
Wire Diameter 0.50mm-19.05mm
Weaving Type Double Crimp,Lock Crimp,Flat Top,Inter Crimp
Aperture 1.00mm-152.00mm
Opening Type Square or Slot
Max width 2500.00mm
Products Type Flat Plates,Rolls, Folding Hook
Material

High Carbon Steel Wire or Stainless Steel Wire.

Mining Screen MeshOpoening:

Opening (Aperture) Wire Diameter Open Area %

Approx. Weight

kg/m2
mm inch mm inch
25.4 1 5.72 0.225 66.62% 13.3
28.58 1 1/8 5.72 0.225 69.43% 12.2
31.75 1 1/4 5.72 0.225 71.80% 10.9
19.05 3/4 6.17 0.243 57.06% 19.1
20 48/61 6.17 0.243 58.41% 18.6
22.23 7/8 6.17 0.243 61.27% 17.3
25.4 1 6.17 0.243 64.73% 15.4
26.99 1 1/16 6.17 0.243 66.25% 14.6
28.58 1 1/8 6.17 0.243 67.64% 13.8
31.75 1 1/4 6.17 0.243 70.11% 12.6
25.4 1 7.19 0.283 60.74% 19.8
28.58 1 1/8 7.19 0.283 63.84% 18.2
31.75 1 1/4 7.19 0.283 66.48% 16.7
38.1 1 1/2 7.19 0.283 70.77% 14.5
25.4 1 7.92 0.312 58.11% 24
28.58 1 1/8 7.92 0.312 61.31% 22
31.75 1 1/4 7.92 0.312 64.06% 20.25
38.1 1 1/2 7.92 0.312 68.54% 17.5
41.28 1 5/8 7.92 0.312 70.40% 16
44.45 1 3/4 7.92 0.312 72.04% 15
50.8 2 7.92 0.312 74.84% 13.5
25.4 1 9.19 0.362 53.92% 30.9
31.75 1 1/4 9.19 0.362 60.14% 26
38.1 1 1/2 9.19 0.362 64.91% 21.4
41.28 1 5/8 9.19 0.362 66.90% 22.4
44.45 1 3/4 9.19 0.362 68.67% 20
50.8 2 9.19 0.362 71.71% 18.1
57.15 2 1/4 9.19 0.362 74.21% 16.2
63.5 2 1/2 9.19 0.362 76.31% 14.85
50.8 2 11.1 0.437 67.35% 25.3
50.8 2 12.7 0.5 64.00% 32.3
57.15 2 1/4 12.7 0.5 66.94% 29.53
63.5 2 1/2 12.7 0.5 69.44% 26.5
76.2 3 12.7 0.5 73.47% 22.7
88.9 3 1/2 12.7 0.5 76.56% 20.2
101.6 4 12.7 0.5 79.01% 17.9


Mining Screen Mesh Application:


Mining Screen Mesh applies to vibrating screens for primary sieving of mine and aggregates, as well as asphalt mixer plant in road building.

Pass Iso 9001 Metal Fine Mesh Screen High Durable Mining Mineral Separeting
Pass Iso 9001 Metal Fine Mesh Screen High Durable Mining Mineral Separeting
Pass Iso 9001 Metal Fine Mesh Screen High Durable Mining Mineral Separeting
